| model | H-150、H-150A |
| Pumping speed (L/S) | 150 |
| Ultimate pressure (Pa) | 1 |
| Motor power (kw) | 15 |
| Steam extraction capacity (kg/h) | about 8.4 |
| Pump inlet maximum pressure of long-term operation(Pa) | 1.3×10? |
| Cooling water consumption (L/min) | 2.5-11.5 |
| Mechanical vacuum pump oil-Brand（SH0528-92) | N100 |
| Mechanical vacuum pump oil-Oil quantity(Kg) | 30 |
| Air inlet diameter (mm) | 100 |
| Air outlet diameter (mm) | 80 |
| Volume (length × width × height) mm³ | 1560×826×1285 |
| Total Weight(Kg) | 880 |
